TYPE T506i & T507i
| TYPE 506 | Friction Build Up Drive(Accumulation) |
| TYPE 506 Adjustable | Adjustable friction build-up Drive (Accumulation) |
| TYPE 507 | Fixed Drive(Continuous Running) |
| PINION DETAILS | Steel driving element - 14 tooth 1/2" Pitch |
| MAXIMUM LOAD CAPACITY | 100 kgs per Roller |
| BUILD UP PRESSURE | 5 - 7% of Unit Load |
| ROLLER DIAMETERS(mm) | 50, 60 |
| SHAFT DIAMETERS(mm) | 14, 15, 17 |
| STANDARD | OPTIONS | |
|---|---|---|
| TUBE MATERIAL |
Mild Steel | Stainless Steel, PVC |
| TUBE FINISH |
Self Colour | Zinc plated, Case hardened, Rubber covered |
| SHAFT MATERIAL |
Mild Steel | Stainless Steel |
| SHAFT FINISH |
Self colour | Zinc plated |
| SHAFT SPECIFICATION |
Female Threaded | Flatted, Male threaded |
| BEARING |
Precision sealed - ZZ | Precision sealed - 2RS, Stainless steel |
